4. Operational Runbook ¶
Table of Contents ¶
4.1 Introduction ¶
This chapter documents the steps to deploy Kubernetes based Reference Implementation (RI-2) according to RA-2. The entire deployment has been tested in OPNFV Labs as a part of the OPNFV Kuberef project . The Kuberef project stores all the code needed to deploy RI-2 and hence serves as a reference platform for CNF vendors to develop and test against. Currently, Kuberef only focuses on bare-metal RI2 deployments, but support for other uses cases (running on Packet, other infrastructure providers, etc.) will be added as the development progresses.
The entire installation is divided into two stages - Host provisioning and Kubernetes provisioning. Host provisioning is the operation of preparing a host before the software stack can be installed on them. This includes (and not limited to) installing an operating system, configuring network so that the hosts are reachable via SSH, configuring storage, etc. This stage can be skipped when using pre-provisioned hardware, infrastructure providers, etc. The Kubernetes provisioning stage is agnostic to the host provisioning stage, in that there is no dependency between the installer used for the Kubernetes provisioning stage and any tools used in the host provisioning stage.
4.2 Prerequisites ¶
You need one physical server acting as a jump server along with minimum of two additional servers on which RI-2 will be deployed. Please refer to Chapter 3 for detailed information on the server and network specifications.
4.3 Installation of the Reference Implementation ¶
This section describes how to get started with RI-2 deployment on bare metal servers. The deployment is done using Kuberef , which is a project that aims to deliver a reference implementation for Kubernetes based on the RA-2.
For the host provisioning stage, a former OPNFV bare-metal provisioner XCI, now referred to as Cloud Infra Automation Framework and hosted by Nordix Labs has been used in the host provisioning stage is used. This framework uses Bifrost for provisioning virtual and bare-metal hosts. It performs this automated deployment by using Ansible playbooks and Ironic . For Kubernetes provisioning, Bare Metal Reference Architecture (BMRA) has been used. This framework uses scripts available on Github (version v2.1.0).
4.3.1 Installation on Bare Metal Infratructure ¶
Start by cloning the Kuberef repository. Before you are able to run the installer some prerequisites must be installed. Details and installation steps can be found in
docs/release/installation/deployment-guide.rst
.
Before initiating a deployment, two configuration templates, referred to as POD Descriptor File (PDF) and Installer Descriptor File (IDF) in OPNFV terminology need to be defined under
hw_config/<vendor>
. Both PDF and IDF files are modeled as YAML schema.
A PDF is a hardware configuration template that includes hardware characteristics of the jumphost host and the set of compute/controller hosts. For each host, the following characteristics should be defined:
- CPU, disk and memory information
- Remote management parameters
- Network interfaces list including name, MAC address, IP address, link speed
IDF includes information about network information required by the installer. All the networks along with possible VLAN, DNS, and gateway information should be defined here. The IDF file also contains configuration options for the Kubernetes deployment using BMRA. These options are described in greater detail below.
More details regarding these descriptor files as well as their schema are very well documented in RI-1 Chapter 8 .
For the high availability requirement at least 3 nodes should be running as master with etcd enabled, but only a single master (and worker) is required to deploy the cluster. Node roles are configured through the vendor specific IDF file.
Most of the configuration options in
hw_config/{deployment}/idf.yaml
shown below are set to specific values according to RA-2 requirements. Some of them might need to be changed depending on the hardware, such as the NIC and CPU configuration.
bmra:
profile: full_nfv
network_roles:
sriov:
- name: eno2 # PF interface name
bus_info: "19:00.1" # PCI ID of the interface (bus:device.function)
device_info: "8086:1572:0200" # Device info for the PCI ID - Can be optained using 'lspci -nn'
driver: iavf # Driver to be used with the interface
sriov_dpdk:
- name: eno4
bus_info: "19:00.3"
device_info: "8086:1572:0200"
driver: vfio-pci
features:
sriov:
enable: true # Enable SR-IOV
sriov_vfs_per_port: 2 # Number of VFs to be created for each interface in network_roles:sriov above
sriov_dpdk_vfs_per_port: 4 # Number of VFs to be created for each interface in network_roles:sriov_dpdk above
sriov_cni: true # Enable SR-IOV CNI plugin
sriov_net_dp: true # Enable SR-IOV Network Device Plugin
hugepages:
enable: true # Enable hugepages
default: 2M # Default hugepage size [2M, 1G]
hugepages_1G: 0 # Number of 1G hugepages to allocate
hugepages_2M: 10240 # Number of 2M hugepages to allocate
isolcpus:
enable: true # Enable CPU isolation in the host
cpus: "8-27,36-55" # List of CPUs (cores/threads) to isolate
nfd: true # Enable Node Feature Discovery
cmk:
enable: true # Enable CPU Manager for Kubernetes
num_shared_cores: 3 # Number of CPU cores to assign to the "shared pool" on each node
num_exclusive_cores: 3 # Number of CPU cores to assign to the "exclusive pool" on each node
topology_manager:
enable: true # Enable Kubernetes built-in Topology Manager
policy: "best-effort" # Policy to use with Topology Manager ["none", "best-effort", "restricted", "single-numa-node"]
tas:
enable: true # Enable Telemetry Aware Scheduling
demo_policy: false # Enable demo policy for Telemetry Aware Scheduling (default: false)
psp: true # Enable Pod Security Policy (admission controller and basic set of rules)
References for the above features:
- CPU Manager for Kubernetes
- SR-IOV Network device plugin for Kubernetes
- Intel Device Plugins for Kubernetes
- Telemtry Aware Scheduling
Additional settings are available in the BMRA templates located in
playbooks/roles/bmra-config/templates
. Changing these might have unexpected results and should generally not be done.
You will also have to modify environmental variables defined in
deploy.env
to match your setup.
Once ready, issue the following command to initiate the deployment
./deploy.sh
Once the deployment is successful, you will have a fully functional RI-2 setup!
The cluster is accessible through the
kubectl
CLI from the master nodes. It is possible to interact with the cluster from a jumphost outside of the cluster by using the kubeconfig file found in
$HOME/.kube/config
. The environment path for using the kubeconfig file on the jumphost can be set with
export
KUBECONFIG=/path/to/config
. Steps for installing
kubectl
can be found
here
Verify that everything is running using the following commands:
$ kubectl get all --all-namespaces
$ kubectl get nodes
$ kubectl get node <node> -o json | jq '.status.allocatable'
# Install jq if needed: yum install -y jq
The list of allocatable resources will vary depending on the configuration, but an example output could look as follows:
{
"cmk.intel.com/exclusive-cores": "3",
"cpu": "61",
"ephemeral-storage": "210667024855",
"hugepages-1Gi": "0",
"hugepages-2Mi": "20Gi",
"intel.com/intel_sriov_dpdk_700_series": "4",
"intel.com/intel_sriov_netdevice": "2",
"memory": "373489916Ki",
"pods": "110"
}
4.3.2 [Placeholder for other Deployment Scenarios] ¶
4.4 Validation of the Reference Implementation ¶
In order to ensure that a given RI-2 meets the requirements specified in the RA-2, a set of testcases specified in RC-2 should be executed. A selection of these testcases is documented in RC-2 Chapter 2 .
For deploying your own CNTT RC2 toolchain, please refer to the steps mentioned in RC-2 Kubernetes Testing Cookbook .
4.5 Automation Tooling ¶
Describe the automation tooling used and any specific configurations needed.
